QuickTime RM-6067 QuickTime Bellhousings

QuickTime RM-6067 QuickTime Bellhousings

$1,207.00
$1,207.00
Sale Sold out

The QuickTime Bellhousing RM-6067 is an SFI 6.1-certified steel bellhousing for Ford small-block and big-block V8s paired with Tremec TKO/T56 transmissions in classic muscle cars. SFI certification means this housing has been tested to contain a clutch explosion at 8,000+ RPM—critical safety equipment.

Fabricated from 0.125-inch steel plate with a full-circumference 0.375-inch block flange, the RM-6067 weighs approximately 22 pounds. The internal design includes a raised rib pattern adding rigidity without interfering with clutch operation. Block dowels are precision-reamed to 0.625 inches, and the transmission register bore is machined within 0.003 inches of true position. Compatible with mechanical and hydraulic linkages.

An exploding clutch at 7,000 RPM carries enough energy to punch through cast aluminum. QuickTime's steel bellhousing contains that energy and protects your feet and legs. The added rigidity also reduces flex that misaligns the transmission input shaft with the crank centerline, protecting your pilot bearing from premature failure.

Your safety isn't negotiable. Running a manual with serious power? You need QuickTime RM-6067. Order yours and protect yourself.
View full details

Frequently Asked Questions

Will the Atech transmission kit improve shift firmness in my automatic transmission?

The Atech transmission recalibration kit improves shift firmness and consistency by modifying the hydraulic control circuit pressure. It typically increases line pressure for crisper shifts that hold better under load and reduce clutch slippage. The Atech kit includes springs, separator plates, and gaskets for a complete valve body modification. Installation requires dropping the transmission pan and removing the valve body taking about two to three hours.

Can I install the Atech shift improvement kit without removing my transmission from the vehicle?

Yes, the Atech shift improvement kit can be installed in-vehicle by removing the transmission oil pan and valve body. You do not need to pull the transmission for this upgrade which saves significant labor time. The Atech kit includes step-by-step instructions for valve body removal and reassembly. Plan for about two to three hours of work in your driveway or garage with basic hand tools.

Does the Atech bellhousing fit both manual and automatic transmission applications?

The Atech bellhousing is designed for specific transmission and engine combinations and is not universal across manual and automatic setups. It is precision-machined to align the transmission input shaft with the engine crankshaft centerline. The Atech bellhousing includes the correct bolt pattern for your specific transmission case. Verify that the Atech bellhousing matches your engine block pattern and transmission case bolt pattern before ordering.

What material is the Atech transmission or bellhousing component made from?

The Atech transmission component is constructed from high-grade materials such as cast aluminum, nodular iron, or billet steel depending on the application. The material is selected for strength, weight, and heat dissipation properties. The Atech part is engineered to contain clutch or converter failures safely in high-performance applications. The material choice ensures the Atech component handles the torque and stress of your engine build.

How does the Atech transmission recalibration affect my vehicle's daily drivability?

The Atech transmission recalibration typically increases shift firmness without making the transmission harsh or uncomfortable for daily driving. In normal driving the firmer shifts are noticeable but not intrusive. Under hard acceleration the Atech recalibration provides positive gear engagement that prevents clutch slip and reduces heat buildup. The kit is designed to improve performance without sacrificing the comfort expected in a daily-driven vehicle.
